Sunhelm Collision Blocker

Your Advanced

Anti-collision Solution

Your terminal needs a more environmentally friendly
and flexible anti-collision marine fender

Safety Foam Fender Suitable For Harsh Environments

Complete Your Form
to Get The Best Quotation

    Foam fenders use lightweight and highly elastic EVA foam as a cushioning medium, which is a better floating fender than inflatable pneumatic fenders. In recent years, a new type of spraying polyurethane (polyurea) technology has been invented to make the surface of the foam fender anti-corrosive and scratch-resistant, and it can adapt to various harsh weather environments. Excellent energy absorption performance, coupled with low reaction force, makes berthing operations easier-especially in difficult conditions. The foam marine fenders is very safe to use, and there is no risk of blasting. Even if the outer skin is damaged, it will not sink. It can still maintain basic functions until you can repair it. Although the price is not as attractive as the pneumatic fender, but its service life is basically twice that of the inflatable fender. Foam fenders are very suitable for dock, especially dock with large tidal range, as well as for ship-to-ship（STS） operations and bridge pier protection.

    What We Do


    Marine Fender Manufacturer



    SunHelm Marine as a comprehensive world leading manufacturer own almost 20 years R&D experience in marine fender and marine airbag system.


    Customized Project Solutions



    Professional and mature technical team could provide complete berthing and mooring project solutions.



    Sufficiant after-sales service



    Comprehensively support any after-sales and using questions reported by our customers. We could offer comprehensive, systematic and creative service as well.

    Foam Fender Features

    • Polyurea protection layer has the resistance of friction, extrusion, oil, sea water and acid & alkali. Maintainness free, do not need check or air inflation during use, and its lifetime can up to 10 -15 years;
    • Reliable performance, convenient installation, aesthetic functionalism, no risk of explosion and high safety;
    • Strong floating performance, lower weight, excellent energy absorption, flexible install location without being influenced by tidal range;
    • Better energy absrption performance and lower reaction force. The increase of reaction force is obvious at 60% deflection;
    • The most widely used in ship fenders. With various specification and flexible design, can be produced as per clients special request.
    • The foam fenders appearance can be customize to different colors. Products are smooth and beautiful with obvious marks.
    • Hanging by chains on both ends, can be easily installed and moved.
    foam fender EVA filled marine fender
    foam fender EVA filled marine fender

    Foam Fender Application

    • For ships, offshore platforms, offshore facilities, marinas and yachts.
    • Should be applied at tugs, work-boats, pilot ships, high seas docks gravity pier dock, especially dock with large tide scope.
    • Applied in naval special warship berthing to provide safety.
    • The very large floating fender can increase the berthing depth to upgrade the dock.
    Now more and more docks and shipyards are beginning to use foam fenders, because this kind of foam fender is really suitable as a dock buffer. There is no need to purchase an inflator separately, and there is no need to worry about air leakage after accidentally being stuck. Basically no extra maintenance is needed. As long as it is used properly, the floating foam fender can even be used for more than 20 years. Because of its safety, many naval ships of many countries also use it for berthing. The polyurea spray coating on the surface of the floating foam fender can increase the elasticity of the product, improve the resistance to seawater corrosion, low temperature resistance, aging resistance, and will never fall off. This makes the foam fender suitable for various harsh weather conditions and will not soften in extremely cold environments. Will not become brittle and easy to peel under extreme heat. The material used in the foam fender-EVA foam-a thermally laminated 100% closed cell foam core, which has the advantages of high energy absorption, low reaction force, durability and will not burst. This manufacturing process does not use adhesives and is a decomposed environmentally friendly material.

    Foam Fender Specifications

    Fender Size Basic Capacity Premium Capacity Supreme Capacity
    D×L(mm) Energy(kNm) Reaction(kN) Pressure(kN/㎡) Energy(kNm) Reaction(kN) Pressure(kN/㎡) Energy(kNm) Reaction(kN) Pressure(kN/㎡)
    700×1500 20 78 104 29 133 172 39 174 224
    1000×1500 28 128 104 49 174 172 62 227 224
    1000×2000 41 147 104 68 254 172 88 329 224
    1200×2000 54 167 104 91 280 172 118 365 224
    1350×2500 91 245 104 152 418 172 198 543 224
    1500×3000 140 343 104 232 578 172 301 752 224
    1700×3000 170 369 104 282 619 172 366 805 224
    2000×3500 273 507 104 455 845 172 592 1099 224
    2000×4000 324 605 104 540 1006 172 701 1308 224
    2000×4500 374 699 104 624 1161 172 811 1508 224
    2500×4000 455 716 104 802 1197 172 1042 1557 224
    2500×5500 720 1072 104 1201 1789 172 1562 2327 224
    3000×4900 859 1063 104 1431 1508 172 1861 2309 224
    3000×6000 1111 1379 104 1852 2296 172 2408 2986 224
    3300×4500 900 1015 104 1499 1691 172 1950 2198 224
    3300×6500 1454 1638 104 2423 2732 172 3150 3551 224



    Such a beautiful foam fender！

    Are you sure not to purchase it from us?

    We can definitely provide you with the best price foam fender

    Get Free Quote

    Foam Fender Structure

    Inner layer: Filled with Closed-cell EVA foam plastics core to absorb elastic energy, which never sink;
    Middle layer: Outer rubber and high strength polyamide cord fabric are adopted to better seal the inner EVA foam;
    Outer layer: Spraying with adjustable new polyurea elastic maerial, the polyurea coating is permanent and that protect the outer layer of fender from chemical corrosion resistance. It has more durability than rubber because it can reduce the chance of denting and scratches and will not get soften or fragile in hot or cold temperature;
    Ends: Equipped with galvanized flange, swivel and can add a protective layer consist of chain and tire net;
    Tyre net sheath: Receiving special treatment, the tyres all have the advantages of firmness, durability and a beautiful surface, which can extend the fender's service life. The structural form of the sheaths can be divided into chain & tyre net, rope & tyre net, wire & tyre net, chain & rubber hose net, etc, and all can be produced as per client's special request.
